3-7 Ton Printed PPGI Steel Coil

Wooden / Marble / Flower designs are beautiful for decoration and making metal box and furniture, etc.

Model Number:HY123

Surface Treatment:Coated

Grade:SGCC/CGCC/SPCC/DX51D/DX52D

Surface Treatment:Coated

Color:RAL K7 CLASSIC or as color sample

Product Name:PRINTED STEEL COIL

Lead Time:Shipped in 25 days after payment

Port:SHANGHAI/NINGBO

Packaging Details:standard seaworthy packing with wooden pallet

Details

PRODUCT INDEX

BASE MATERIAL	HDGI HDGL
THICKNESS	0.23-0.8mm
WIDTH	914-1250mm
INTERNAL DIAMETER	508mm
WEIGHT	3-7TON
PAINT	PE/PVDF
STRUCTURE	TOP 2/BACK 1

PERFORMANCE INDICATORS

TEST ITEM	TOP	BACK
PAINT THICKNESS	>5+18	5-7
GLOSSY	high 70±5/middle50土5/low30±5	35±5
COATING HARDNESS	≥H	≥H
T BELT	≤3T	≤4T
IMPACT RESISTANCE	≥9J	≥6J
DISSOLVENT RESISTANCE	≥100	≥50
SALT SPAY TEST	≥720hr
ACID RESISTANCE	SOAKED IN 5% HCL SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF
ALKALI RESISTANCE	SOAKED IN 5% NAOH SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF

3-7 ton Printed PPGI Steel Coil refers to steel coils that have a weight range of 3-7 tons and have been pre-coated with paint or other materials before being used in construction. The weight range of 3-7 tons is considered to be a medium range weight, and it is suitable for many large-scale construction projects. It is important to note that the weight of the steel coil does not only depend on the length of the coil but also on the thickness of the steel used for the coil.It has good welding performance and easy to weld on all kinds of machine tools ,especially suitable for large press working which does not need coating etc.This PPGI steel coil is applied to the production of cold-formed profiles in the construction and other industries.
