Printed PPGI Coil for Building HY311

Wooden / Marble / Flower designs are beautiful for decoration and making metal box and furniture, etc.

This pattern is a traditional geometric pattern, commonly known as the Arabesque Pattern. This pattern is usually based on geometric shapes and incorporates elements such as plant vines and leaves to form a symmetrical, repetitive design. In this specific example, the pattern of leaves and vines is placed within a diamond-shaped frame, creating a complex and elegant visual effect.

Details

PRODUCT INDEX

BASE MATERIAL	HDGI HDGL
THICKNESS	0.23-0.8mm
WIDTH	914-1250mm
INTERNAL DIAMETER	508mm
WEIGHT	3-7TON
PAINT	PE/PVDF
STRUCTURE	TOP 2/BACK 1

PERFORMANCE INDICATORS

TEST ITEM	TOP	BACK
PAINT THICKNESS	>5+18	5-7
GLOSSY	high 70±5/middle50土5/low30±5	35±5
COATING HARDNESS	≥H	≥H
T BELT	≤3T	≤4T
IMPACT RESISTANCE	≥9J	≥6J
DISSOLVENT RESISTANCE	≥100	≥50
SALT SPAY TEST	≥720hr
ACID RESISTANCE	SOAKED IN 5% HCL SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF
ALKALI RESISTANCE	SOAKED IN 5% NAOH SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF

PPGI coils are made from galvanized steel or galvalume steel (galvanized steel with aluminum-zinc alloy coating) that provides excellent corrosion resistance and structural strength.
Pre-painting Process: The coils undergo a pre-painting process where a primer and multiple layers of paint are applied in a continuous coating line. This ensures uniform coverage and adherence of the paint layers to the metal surface.
Printed Design: Unlike solid color PPGI, printed PPGI coils are designed to mimic the appearance of natural materials such as wood, marble, granite, or other textures. This allows for greater versatility in architectural designs, offering a visually appealing alternative to traditional building materials.
