Stone Pattern Printed PPGI Coated Coil KDG465

Wooden / Marble / Flower designs are beautiful for decoration and making metal box and furniture, etc.

Details

PRODUCT INDEX

BASE MATERIAL	HDGI HDGL
THICKNESS	0.23-0.8mm
WIDTH	914-1250mm
INTERNAL DIAMETER	508mm
WEIGHT	3-7TON
PAINT	PE/PVDF
STRUCTURE	TOP 2/BACK 1

PERFORMANCE INDICATORS

TEST ITEM	TOP	BACK
PAINT THICKNESS	>5+18	5-7
GLOSSY	high 70±5/middle50土5/low30±5	35±5
COATING HARDNESS	≥H	≥H
T BELT	≤3T	≤4T
IMPACT RESISTANCE	≥9J	≥6J
DISSOLVENT RESISTANCE	≥100	≥50
SALT SPAY TEST	≥720hr
ACID RESISTANCE	SOAKED IN 5% HCL SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF
ALKALI RESISTANCE	SOAKED IN 5% NAOH SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF

Base material selection: High-quality HDGI (hot-dip galvanized coil) or HDGL (hot-dip galvanized coil) is used to ensure the strength and durability of the product.

Wide range of thickness and width: Thickness ranging from 0.23mm to 0.8mm and width ranging from 914mm to 1250mm can be provided according to customer needs to meet the requirements of different projects.

Excellent appearance effect: Through the stone grain printing technology, the surface presents an imitation stone texture, which adds a natural and beautiful appearance to the product, making it popular in architectural decoration and furniture manufacturing.

Excellent anti-corrosion performance: The coating adopts PE (polyethylene) or PVDF (polyvinylidene fluoride), which provides excellent weather resistance and corrosion resistance, and can be used for a long time in various harsh environments without failure.

Lightweight and easy to process: The product weight is between 3 and 7 tons, which is suitable for transportation and processing operations, giving it good application flexibility in the manufacturing industry.

Customizable structure: The coating structure design of top layer 2 / back layer 1 provides better wear resistance and anti-fouling ability, extending the service life of the product.

Stone Pattern Printed PPGI Coated Coil is not only a functional building material, but also a combination of art and design, bringing unique visual effects and lasting protective performance to the project.
