Printed PPGI Color Coated Steel Coil

Wooden / Marble / Flower designs are beautiful for decoration and making metal box and furniture, etc.

Model Number:HY763

Length:different as each coil

Surface Treatment:Coated

Special Use:High-strength Steel Plate

Q：How about your production ability?
A: We have one galvanized steel line and one ppgi production line, yearly steel coil production ability is more than 200000TON.
Q：How many employees in company? And how many engineer?
A: We have more than 100 experienced employees, and 5 professional engineer.

Details

PRODUCT INDEX

BASE MATERIAL	HDGI HDGL
THICKNESS	0.23-0.8mm
WIDTH	914-1250mm
INTERNAL DIAMETER	508mm
WEIGHT	3-7TON
PAINT	PE/PVDF
STRUCTURE	TOP 2/BACK 1

PERFORMANCE INDICATORS

TEST ITEM	TOP	BACK
PAINT THICKNESS	>5+18	5-7
GLOSSY	high 70±5/middle50土5/low30±5	35±5
COATING HARDNESS	≥H	≥H
T BELT	≤3T	≤4T
IMPACT RESISTANCE	≥9J	≥6J
DISSOLVENT RESISTANCE	≥100	≥50
SALT SPAY TEST	≥720hr
ACID RESISTANCE	SOAKED IN 5% HCL SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF
ALKALI RESISTANCE	SOAKED IN 5% NAOH SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF

The surface treatment of Printed PPGI Color Coated Steel Coil is coated. The steel coil is first coated with a layer of zinc to protect against corrosion, and then coated with a layer of paint on one side, which includes the printed design or pattern, and a solid color on the other side. This coating process is called "roll coating" which applies the paint in a precise and consistent manner. The coating can be applied in a wide range of colors to match the design or architectural style of the building or structure. The coating on the steel coil not only improves its aesthetic appeal but also protect steel against corrosion, making it more durable and long-lasting.
